Section 1: Product Identification
   (2R,4R)-(+)-2-(Diphenylphosphinomethyl)-4-(diphenylphosphino)-N-(t-butoxycarbonyl)pyrrolidine, min. 97%
   Chemical Name:
   (R,R-BPPM)
   CAS Registry Number:       72598-03-9
   Formula:       C34H49NO2P2
   EINECS Number:       none
   Chemical Family:       organophosphine ligand
   (R,R-BPPM); (2R,4R)-tert-butyl 4-(diphenylphosphino)-2-((diphenylphosphino)methyl)pyrrolidine-1-carboxylate
   Synonym:

---

Section 2: Composition and Information on Ingredients
   Ingredient       CAS Number       Percent       ACGIH (TWA)       OSHA (PEL)
   Title compound       72598-03-9       100%       no data       no data

---

Section 3: Hazards Identification
   Emergency Overview:       Irritating to skin, eyes and respiratory tract. May be harmful if swallowed.
   Primary Routes of Exposure:       Ingestion, inhalation
   Eye Contact:       Causes slight to mild irritation of the eyes.
   Skin Contact:       Causes slight to mild irritation of the skin.
   Inhalation:       Irritating to the nose, mucous membranes and respiratory tract.
   Ingestion:       No information available on the physiological effects of ingestion. May be harmful if swallowed.
   Acute Health Affects:       Irritating to skin, eyes and respiratory tract.
   Chronic Health Affects:       No information on long-term chronic effects.
   NTP:       No
   IARC:       No
   OSHA:       No

---

SECTION 4: First Aid Measures
   Immediately flush the eyes with copious amounts of water for at least 10-15 minutes. A victim may need
   Eye Exposure:
   assistance in keeping their eye lids open. Get immediate medical attention.
   Wash the affected area with water. Remove contaminated clothes if necessary. Seek medical assistance if
   Skin Exposure:
   irritation persists.
   Remove the victim to fresh air. Closely monitor the victim for signs of respiratory problems, such as difficulty
   Inhalation:
   in breathing, coughing, wheezing, or pain. In such cases seek immediate medical assistance.
   Seek medical attention immediately. Keep the victim calm. Give the victim water (only if conscious). Induce
   Ingestion:
   vomiting only if directed by medical personnel.

---

SECTION 5: Fire Fighting Measures
   Flash Point:       not applicable
   Autoignition Temperature:       no data
   Explosion Limits:       no data
   Extinguishing Medium:       carbon dioxide, dry powder or foam
   If this product is involved in a fire, fire fighters should be equipped with a NIOSH approved positive pressure
   Special Fire Fighting Procedures:
   self-contained breathing apparatus and full protective clothing.
   Hazardous Combustion and       If involved in a fire this material may emit irritating fumes.
   Decomposion Products:
   Unusual Fire or Explosion Hazards: No unusual fire or explosion hazards.

---

SECTION 6: Accidental Release Measures
   Small spills can be mixed with vermiculite, sodium carbonate or other suitable non-combustible adsorbent and
   Spill and Leak Procedures:
   swept up.

---

SECTION 7: Handling and Storage
   Store in a tightly sealed container under an inert atmosphere of nitrogen or argon. Keep in a cool, dry,
   Handling and Storage:
   well-ventillated area.

---

SECTION 8: Exposure Controls and Personal Protection
   Eye Protection:       Always wear approved safety glasses when handling a chemical substance in the laboratory.
   Skin Protection:       Wear protective clothing and gloves.
   Ventilation:       Handle the material in an efficient fume hood.
   If ventilation is not available a respirator should be worn. The use of respirators requires a Respirator
   Respirator:
   Protection Program to be in compliance with 29 CFR 1910.134.
   Ventilation:       Handle the material in an efficient fume hood.
   Additional Protection:       No additional protection required.

---

SECTION 9: Physical and Chemical Properties
   Color and Form:       white powder
   Molecular Weight:       565.71
   Melting Point:       no data
   Boiling Point:       no data
   Vapor Pressure:       no data
   Specific Gravity:       no data
   Odor:       none
   Solubility in Water:       insoluble

---

SECTION 10: Stability and Reactivity
   Stability:       air sensitive
   Hazardous Polymerization:       no hazardous polymerization
   Conditions to Avoid:       prolonged exposure to air
   Incompatibility:       strong oxidizing agents
   Decomposition Products:       carbon monoxide, carbon dioxide, phorsphorous oxides and organic fumes

---

SECTION 11: Toxicological Information
   RTECS Data:       No information available in the RTECS files.
   Carcinogenic Effects:       no data
   Mutagenic Effects:       no data
   Tetratogenic Effects:       no data

---

SECTION 12: Ecological Information
   Ecological Information:       No information available

---

SECTION 13: Disposal Considerations
   Disposal:       Dispose of according to local, state and federal regulations.

---

SECTION 14: Transportation
   Shipping Name (CFR):       Non-hazardous
   Hazard Class (CFR):       NA
   Additional Hazard Class (CFR):       NA
   Packaging Group (CFR):       NA
   UN ID Number (CFR):       NA
   Shipping Name (IATA):       Non-hazardous
   Hazard Class (IATA):       NA
   Additional Hazard Class (IATA):       NA
   Packaging Group (IATA):       NA
   UN ID Number (IATA):       NA

---

SECTION 15: Regulatory Information
   TSCA:       Not listed in the TSCA inventory
   SARA (Title 313):       Not reportable under SARA 313
   Second Ingredient:       none

---

SECTION 16 - ADDITIONAL INFORMATION
N/A
